Design and performance analysis of 12Slot-14Pole HEFSM with outer-rotor configuration

Ahmad, Md Zarafi and Sulaiman, Erwan and Khan, Faisal and Haron, Zainal Alam (2014) Design and performance analysis of 12Slot-14Pole HEFSM with outer-rotor configuration. In: 2014 IEEE 8th International Power Engineering and Optimization Conference (PEOCO2014), 24-25 March 2014, Langkawi, Kedah, Malaysia..

[img]
Preview
PDF
706Kb

Abstract

This paper presents the performance analysis of 12Slot-14Pole hybrid excitation flux switching machine (HEFSM) with outer-rotor configuration. Nowadays, research on flux switching machines (FSMs) become an attractive research topic due to several excessive advantages of robust rotor structure, high torque and power capability, and low manufacturing cost that suitable for heavy applications. The FSMs that constructed with two flux sources namely permanent magnet (PM) and flux excitation coil (FEC) which also known as hybrid excitation flux has additional advantage of flux controllable. Furthermore, the outer-rotor configuration of the machines can provides higher torque density and appropriate for in-wheel direct drive application. Based on 2-D finite element analysis (FEA), the design improvement has been made on the initial design machine shows that there is great enhancement on torque and power.

Item Type:Conference or Workshop Item (Paper)
Subjects:T Technology > TK Electrical engineering. Electronics Nuclear engineering > TK2000-2891 Dynamoelectric machinery and auxiliaries
Divisions:Faculty of Electrical and Electronic Engineering > Department of Electrical Power Engineering
ID Code:8468
Deposited By:Mr. Mohammad Shaifulrip Ithnin
Deposited On:24 May 2017 15:57
Last Modified:24 May 2017 15:57
